11/64″ Dia-3-1/4″ OAL-HSS-Center Cut-DE Mini EM-4 FL
SQ End Mill; 11/64″ Dia. × 7/8″ LOC × 3/16″ Shank Dia. × 3-1/4″ OAL ; 4 FL ; HSS ; Uncoated
| Cutting Diameter (DC) | 11/64″ | Flute Count (NOF) | 4 |
| Connection Diameter Machine Side (DCONMS) | 3/16″ | Usable Length (LU) | 7/8″ |
| Depth of Cut Maximum (APMX) | 7/8″ | Tool Type | Double-End|Center Cut |
| Overall Length (OAL) | 3-1/4″ | Length Group | Miniature |
| Cutting Edge Material | HSS | Decimal Equivalent | 0.171875″ |
| Coating | Uncoated |
Product Features
| Remarks | •4-Flute Long Length Double End Miniature End Mills •3/16 Shank • Center Cutting • High Speed Steel | Country of Origin | China |
